8340P-40422

26 kW Diesel DC Generator


The Most Efficient Means to Charge Batteries and Power Loads using Diesel
Fully Automatic Battery Charging Options

Features

  • Maximum output is 26 kW at 2600 RPM
  • Available in all voltages from 48 to 500 Vdc
  • Variable speed with a typical 500 RPM span from
    full load to no load
  • Lower engine speed options available
  • 4 cylinder diesel, quiet and with low vibration
  • Engine operational life is 12,000 to 20,000 hours
    based on selected engine RPM and load
  • Temperature compensated battery charging
  • Oil changes at 500 hours with 1,000 hour option
  • Light weight
  • Alternator exceeding 85% efficiency
